I. LW440 Mud Pump Technical Specification
Rated input power |
328KW (440HP) |
Rated Stroke |
320冲/分（320SPM）（LW440） |
Stroke |
152.4mm （6″） |
Gear Ratio |
4.578 ：1 |
Max. operation pressure |
35 Mpa (LW440) |
Valve chamber Valve-Over |
API 4# |
Max. liner dia. |
4-1/2″ (LW440) |
Max. liner mud pressure |
(160冲/分) 16.9 Mpa |
Dia. of suction manifold 6″ |
(150 #) Flange |
Dia. of discharge manifold 3″ |
(900 #) Flange |
Dia. pinion Shaft |
95.25mm （3.75″） |
Dia. pinion Key |
22.174×15.9 mm |
Dimension：（No included base） |
2479×1219×1103 mm |
Weight |
4463 Kg |
II. Tructure Character
The pump is compact structure, small volume, lightweight, integrated herringbone gear pair, large transmit torque and smooth run. Crankshaft is welding forged and light weight without libration.
LW440 Mud Pump Single-acting Triplex Pump can be used widely in oilfield operation. Liner size from 3-1/4″—4-1/2″ is better-adopted piston structure for workover operation and low well drilling operation while plunger structure for liner size from 2—31/4″ for high- pressure operation.
III. Performance Parameter Table
LW-440 MUD PUMP |
(stroke/Min.) |
170 |
120 |
70 |
||||||
Rated Input (HP) |
260 |
200 |
200 |
|||||||
Liner Dia.（in） |
Pressure |
Gallon/Turn |
Liter/Turn |
G/m |
L/m |
G/m |
L/m |
G/m |
L/m |
|
psi |
Mpa |
|||||||||
41/2 |
1710 |
11.793 |
1.239 |
4.690 |
211 |
799 |
149 |
564 |
87 |
329 |
4 |
2169 |
14.959 |
0.979 |
3.706 |
167 |
633 |
118 |
447 |
69 |
261 |
31/2 |
2816 |
19.421 |
0.750 |
2.839 |
127 |
481 |
90 |
341 |
52 |
197 |
G/m： Gallon/min | L/m: Liter/min
LW-440Parameter |
(stroke/Min.) |
320 |
270 |
220 |
||||||
Rated Input (HP) |
440 |
380 |
320 |
|||||||
Liner Dia.（in） |
Pressure |
Gallon/Turn |
Liter/Turn |
G/m |
L/m |
G/m |
L/m |
G/m |
L/m |
|
psi |
Mpa |
|||||||||
41/2 |
1710 |
11.793 |
1.239 |
4.690 |
397 |
1503 |
335 |
1268 |
273 |
1033 |
4 |
2169 |
14.959 |
0.979 |
3.706 |
313 |
1185 |
264 |
999 |
215 |
814 |
31/2 |
2816 |
19.421 |
0.750 |
2.839 |
240 |
908 |
202 |
764 |
165 |
625 |
G/m： Gallon/min | L/m: Liter/min
